Baudouin Diesel Generator ARK-B 900 N5

ARK-B 900 N5 Diesel Generator – High-Capacity Power for Industrial and Commercial Use

The ARK-B 900 N5 diesel generator from Arken Generator produces 825 kVA prime and 910 kVA standby power with the Baudouin 8M33G900/5 8-cylinder, turbocharged, water-cooled engine. Built for high-demand environments, it combines power, efficiency, and operational stability for continuous use.

Equipped with a NEKRA ARK 6D alternator featuring 96.1% efficiency, ±1% voltage regulation, and <5% THD, it delivers clean and dependable electricity. Compliant with ISO 8528 and ISO 3046 standards, the ARK-B 900 N5 operates at 88 dBA and includes a 2-year or 1000-hour warranty, ensuring long-lasting performance.

Power Prime (kVA / kW)

825 / 660

Power Standby (kVA / kW)

910 / 728

Speed (r.p.m)

1500

Standard Voltage

400/230VAC

Power Factor(Cos Phi)

0.8
BrandBAUDOUIN
Power PRP [kW]730
Model8M33G900/5
N° of Cylinders / Valves8/32
Engine Type4
Displacement [lt]26.14
AspirationTurbocharged - Aftercooled
Bore[mm] x Stroke[mm]150x185
Compression Ratio15:1
Air FilterHeavy Duty
Cooling MethodWater Cooled (water + %50 antifreeze)
Total Coolant Capacity (lt)152
Governor TypeElectronic
Electrical System24VDC
Battery Charger Current55
Oil Capacity [lt]105
Exhaust Gas Flow PRP [m3/min]138,5
Exhaust Gas Temp. [°C]≤550
Air Flow PRP [m3/min]43.7
Cooling Air Flow PRP [m3/min]870
Starter Power (kW)8.5
Standard Battery Voltage [V]24VDC
Standard Battery Capacity4x105Ah
Standard Battery TypeMaintenance-Free Lead Acid
BrandNEKRA
ModelARK 6D
Voltage400 /230 VAC
Number of Phase3
Power Factor0.8
Number of Poles4
Connection TypeStar
BearingSingle
