Mitsubishi Diesel Generator ARK-M 2750 N5

ARK-M 2750 N5 Diesel Generator – Maximum Power for Continuous Industrial Operation

The ARK-M 2750 N5 diesel generator from Arken Generator provides 2500 kVA prime and 2750 kVA standby power, driven by the Mitsubishi S16R2-PTAW2-E 16-cylinder, turbocharged, fresh-water cooled engine. Engineered for maximum performance and reliability, it meets the highest standards for large-scale industrial facilities.

Its Nekra ARK 7K alternator delivers 96.7 % efficiency, ±1 % voltage regulation, and < 5 % THD, ensuring steady and clean output. Certified to ISO 8528 and ISO 3046, the ARK-M 2750 N5 operates at 75 dBA and includes a 2-year / 1000-hour warranty, offering unparalleled power and efficiency for continuous operations

Power Prime (kVA / kW)

2500 / 2000

Power Standby (kVA / kW)

2750 / 2200

Speed (r.p.m)

1500

Standard Voltage

400/230VAC

Power Factor(Cos Phi)

0.8
BrandMitsubishi
Power PRP [kW]2209
ModelS16R2-PTAW2-E
N° of Cylinders / Valves16/64
Engine Type 4
Displacement [lt]79,9
AspirationTurbocharged And Aircooler (Fresh water to cooler)
Bore[mm] x Stroke[mm]170x220
Compression Ratio14.0:1
Air FilterHeavy Duty
Cooling MethodWater Cooled (water + %50 antifreeze)
Total Coolant Capacity (lt)760
Governor TypeElectronic
Electrical System 24VDC
Battery Charger Current30A
Oil Capacity [lt]290
Exhaust Gas Flow PRP [m3/min]506
Exhaust Gas Temp. [°C]N/A
Air Flow PRP [m3/min]191
Cooling Air Flow PRP [m3/min]2478
Starter Power (kW)2x7.5kW
Standard Battery Voltage [V] 24VDC
Standard Battery Capacity4x150Ah
Standard Battery TypeMaintenance-Free Lead Acid
BrandNEKRA
ModelARK 7K
Voltage400 /230 VAC
Number of Phase3
Power Factor0,8
Number of Poles4
Connection Type Star
BearingSingle

Datasheet
