Perkins Diesel Generator ARK-P 1400 N5

ARK-P 1400 N5 Diesel Generator

The ARK-P 1400 N5 diesel generator, designed by Arken Generator, delivers 1250 kVA prime and 1375 kVA standby power, providing high-performance and reliable energy for industrial and commercial operations. Powered by the Perkins 4012-46TWG2A 12-cylinder, turbocharged, air-to-water charge-cooled engine, it ensures outstanding fuel efficiency, superior durability, and stable operation under continuous load. The NEKRA ARK 6G alternator with electronic AVR offers ±1% voltage regulation and <5% THD, delivering clean, stable, and consistent power output. Built in full compliance with ISO 8528 and ISO 3046 standards, the ARK-P 1400 N5 operates at 90.5 dBA, features a robust corrosion-resistant canopy, and is backed by a 2-year or 1000-hour warranty, making it a dependable and efficient solution for both continuous and standby power generation.

Power Prime (kVA / kW)

1250 / 1000

Power Standby (kVA / kW)

1375 / 1100

Speed (r.p.m)

1500

Standard Voltage

400/230VAC

Power Factor(Cos Phi)

0.8
BrandPerkins
Power PRP [kW]1055
Model4012-46TWG2A
N° of Cylinders / Valves12/ 48
Engine Type4
Displacement [lt]45.8
AspirationTurbocharged - Air to water charge cooled
Bore[mm] x Stroke[mm]160x190
Compression Ratio13:1
Air FilterHeavy Duty
Cooling MethodWater Cooled (water + %50 antifreeze)
Total Coolant Capacity (lt)201
Governor TypeElectronic
Electrical System24VDC
Battery Charger Current40A
Oil Capacity [lt]177
Exhaust Gas Flow PRP [m3/min]235
Exhaust Gas Temp. [°C]422
Air Flow PRP [m3/min]103
Cooling Air Flow PRP [m3/min]28
Starter Power (kW)16,4kW
Standard Battery Voltage [V]24VDC
Standard Battery Capacity4x150Ah
Standard Battery TypeMaintenance-Free Lead Acid
BrandNekra
ModelARK 6G
Voltage400 /230 VAC
Number of Phase3
Power Factor0.8
Number of Poles4
Connection TypeStar
BearingSingle
