Cummins Diesel Generator ARK-C 1450 L5

ARK-C 1450 L5 Diesel Generator – Maximum Power, Efficiency, and Industrial Reliability

The ARK-C 1450 L5 diesel generator, developed by Arken Generator, delivers 1295 kVA prime and 1430 kVA standby power, providing superior performance, efficiency, and durability for heavy-duty industrial and commercial operations. Powered by the Cummins KTA50-G3 16-cylinder, turbocharged, aftercooled, water-cooled engine, it ensures exceptional fuel economy, smooth operation, and long-term reliability under continuous load. Its LINZ PRO40MD4 alternator with electronic AVR provides ±1% voltage regulation and <5% THD, guaranteeing clean and stable energy output. Built to meet ISO 8528 and ISO 3046 standards, the ARK-C 1450 L5 operates at 85 dBA, features a corrosion-resistant canopy, and comes with a 1-year or 1000-hour warranty, making it a dependable and efficient power generation solution for both continuous and standby applications.

Power Prime (kVA / kW)

1295 / 1036

Power Standby (kVA / kW)

1430 / 1144

Speed (r.p.m)

1500

Standard Voltage

400/230VAC

Power Factor(Cos Phi)

0,8
BrandCummins
Power PRP [kW]1097
ModelKTA50-G3
N° of Cylinders / Valves16
Engine Type4 Stroke
Displacement [lt]50,3
AspirationTurbocharger and Aftercooler System
Bore[mm] x Stroke[mm]159x159
Compression Ratio13.9:1
Air FilterHeavy Duty
Cooling Method Water Cooled (water + %50 antifreeze)
Total Coolant Capacity (lt)415
Governor TypeElectronic
Electrical System24VDC
Battery Charger Current35
Oil Capacity [lt]177
Exhaust Gas Temp. [°C]3728
Air Flow PRP [m3/min]≤520
Cooling Air Flow PRP [m3/min]1605
Starter Power (kW)TBA
Standard Battery Voltage [V]24VDC
Standard Battery Capacity4x150Ah
Standard Battery Type Maintenance-Free Lead Acid
BrandLinz
ModelPRO40MD4
Voltage400 /230 VAC
Number of Phase3
Power Factor0,8
Number of Poles4
Connection TypeStar
BearingSingle

Datasheet
