Perkins Diesel Generator ARK-P 1500 N5

ARK-P 1500 N5 Diesel Generator

The ARK-P 1500 N5 diesel generator, produced by Arken Generator, delivers 1320 kVA prime and 1440 kVA standby power, ensuring exceptional performance and reliability for industrial and commercial applications. Powered by the Perkins 4012-46TWG3A 12-cylinder, turbocharged, air-to-air cooled engine, it offers outstanding fuel efficiency, low emissions, and long-term durability under heavy load. Its NEKRA ARK 7E alternator with electronic AVR provides ±1% voltage regulation and <5% THD, guaranteeing clean and stable energy output. Built in compliance with ISO 8528 and ISO 3046 standards, the ARK-P 1500 N5 operates at 90.5 dBA, features a corrosion-resistant canopy, and comes with a 2-year or 1000-hour warranty, making it a dependable and high-performance power generation solution for continuous and standby use.

Power Prime (kVA / kW)

1320 / 1056

Power Standby (kVA / kW)

1440 / 1152

Speed (r.p.m)

1500

Standard Voltage

400/230VAC

Power Factor(Cos Phi)

0.8
BrandPerkins
Power PRP [kW]1149
Model4012-46TWG3A
N° of Cylinders / Valves12/ 48
Engine Type4
Displacement [lt]45.842
AspirationTurbocharged - Air to air cooled
Bore[mm] x Stroke[mm]160x190
Compression Ratio13:1
Air FilterHeavy Duty
Cooling MethodWater Cooled (water + %50 antifreeze)
Total Coolant Capacity (lt)201
Governor TypeElectronic
Electrical System24VDC
Battery Charger Current40A
Oil Capacity [lt]177
Exhaust Gas Flow PRP [m3/min]245
Exhaust Gas Temp. [°C]479
Air Flow PRP [m3/min]108
Cooling Air Flow PRP [m3/min]28
Starter Power (kW)16,4kW
Standard Battery Voltage [V]24VDC
Standard Battery Capacity4x150Ah
Standard Battery TypeMaintenance-Free Lead Acid
BrandNekra
ModelARK 7E
Voltage400 /230 VAC
Number of Phase3
Power Factor0.8
Number of Poles4
Connection TypeStar
BearingSingle
