Baudouin Diesel Generator ARK-B 55 N5

ARK-B 55 N5 Diesel Generator – Reliable Energy for Continuous Operation

The ARK-B 55 N5 diesel generator by Arken Generator delivers 48 kVA prime and 52 kVA standby power with the Baudouin 4M06G50/5 engine. Featuring a 4-cylinder, turbocharged, aftercooled, and water-cooled design, it ensures high efficiency and stable performance for industrial and commercial applications.

With a NEKRA ARK 224D alternator achieving 90.8% efficiency, ±1% voltage regulation, and <5% THD, it provides steady and clean output. Certified under ISO 8528 and ISO 3046, the ARK-B 55 N5 operates quietly at 70.8 dBA and includes a 2-year or 1000-hour warranty, offering dependable performance in all environments.

Power Prime (kVA / kW)

48 / 38,4

Power Standby (kVA / kW)

52 / 41,6

Speed (r.p.m)

1500

Standard Voltage

400/230VAC

Power Factor(Cos Phi)

0.8
BrandBAUDOUIN
Power PRP [kW]44
Model4M06G50/5
N° of Cylinders / Valves4/8
Engine Type4
Displacement [lt]2.3
AspirationTurbocharge and Aftercooler System
Bore[mm] x Stroke[mm]89x92
Compression Ratio17,5:1
Air FilterHeavy Duty
Cooling MethodWater Cooled (water + %50 antifreeze)
Total Coolant Capacity (lt)12.9
Governor TypeElectronic
Electrical System12VDC
Battery Charger Current55
Oil Capacity [lt]9.5
Exhaust Gas Flow PRP [m3/min]8,82
Exhaust Gas Temp. [°C]≤650
Air Flow PRP [m3/min]2.6
Cooling Air Flow PRP [m3/min]102
Starter Power (kW)3,7
Standard Battery Voltage [V]12VDC
Standard Battery Capacity1x60Ah
Standard Battery TypeMaintenance-Free Lead Acid
BrandNEKRA
ModelARK 224D
Voltage400 /230 VAC
Number of Phase3
Power Factor0.8
Number of Poles4
Connection TypeStar
BearingSingle

Datasheet
