Perkins Diesel Generator ARK-P 900 L5

ARK-P 900 L5 Diesel Generator

The ARK-P 900 L5 diesel generator, engineered by Arken Generator, delivers 800 kVA prime and 900 kVA standby power, providing high-performance and long-lasting energy for industrial and commercial applications. Powered by the Perkins 4006-23TAG3A 6-cylinder, turbocharged, air-to-air cooled engine, it ensures superior fuel efficiency, low emissions, and continuous reliability under demanding conditions. The LINZ PRO35L H/4 alternator with electronic AVR offers ±1% voltage regulation and <3% THD, guaranteeing clean, stable, and uninterrupted power output. Built to meet ISO 8528 and ISO 3046 standards, the ARK-P 900 L5 operates quietly at 85 dBA, features a corrosion-resistant canopy, and is backed by a 2-year or 1000-hour warranty, making it an ideal choice for heavy-duty and continuous power generation.

Power Prime (kVA / kW)

800 / 640

Power Standby (kVA / kW)

900 / 720

Speed (r.p.m)

1500

Standard Voltage

400/230VAC

Power Factor(Cos Phi)

0.8
BrandPerkins
Power PRP [kW]675
Model4006-23TAG3A
N° of Cylinders / Valves6/24
Engine Type4
Displacement [lt]22.9
AspirationTurbocharged - Air to air cooled
Bore[mm] x Stroke[mm]160x190
Compression Ratio13.6:1
Air FilterHeavy Duty
Cooling MethodWater Cooled (water + %50 antifreeze)
Total Coolant Capacity (lt)120
Governor TypeElectronic
Electrical System24VDC
Battery Charger Current55
Oil Capacity [lt]113.4
Exhaust Gas Flow PRP [m3/min]193
Exhaust Gas Temp. [°C]550
Air Flow PRP [m3/min]69
Cooling Air Flow PRP [m3/min]870
Starter Power (kW)7,5kW
Standard Battery Voltage [V]24VDC
Standard Battery Capacity4x75Ah
Standard Battery TypeMaintenance-Free Lead Acid
BrandLinz
ModelPRO35L H/4
Voltage400 /230 VAC
Number of Phase3
Power Factor0.8
Number of Poles4
Connection TypeStar
BearingSingle

Datasheet
