Perkins Diesel Generator ARK-P 90 S5

ARK-P 90 S5 Diesel Generator

The ARK-P 90 S5 diesel generator, developed by Arken Generator, delivers 82 kVA prime and 90 kVA standby power, providing dependable, fuel-efficient, and high-performance energy for commercial and industrial applications. Powered by the Perkins 1104A-44TG2 4-cylinder, turbocharged, water-cooled engine, it ensures exceptional durability, smooth operation, and reduced fuel consumption. Its STAMFORD UCI224G alternator with electronic AVR provides ±1% voltage regulation and <5% THD, delivering clean and stable power output. Built in compliance with ISO 8528 and ISO 3046 standards, the ARK-P 90 S5 operates quietly at 71.9 dBA, features a corrosion-resistant canopy, and comes with a 1-year or 1000-hour warranty, making it a robust and efficient power generation solution for continuous and backup applications.

Power Prime (kVA / kW)

82 / 65

Power Standby (kVA / kW)

90 / 72

Speed (r.p.m)

1500

Standard Voltage

400/230VAC

Power Factor(Cos Phi)

0.8
BrandPerkins
Power PRP [kW]71.9
Model1104A-44TG2
N° of Cylinders / Valves4/8
Engine Type4
Displacement [lt]4.4
AspirationTurbocharged
Bore[mm] x Stroke[mm]105x127
Compression Ratio17.25:1
Air FilterHeavy Duty
Cooling MethodWater Cooled (water + %50 antifreeze)
Total Coolant Capacity (lt)13
Governor TypeMechanical
Electrical System12VDC
Battery Charger Current65A
Oil Capacity [lt]8
Exhaust Gas Flow PRP [m3/min]12,5
Exhaust Gas Temp. [°C]555
Air Flow PRP [m3/min]4.8
Cooling Air Flow PRP [m3/min]89
Starter Power (kW)3 kW
Standard Battery Voltage [V]12VDC
Standard Battery Capacity1x75Ah
Standard Battery TypeMaintenance-Free Lead Acid
BrandStamford
ModelUCI224G
Voltage400 /230 VAC
Number of Phase3
Power Factor0.8
Number of Poles4
Connection TypeStar
BearingSingle
