Perkins Diesel Generator ARK-P 1500 S5

ARK-P 1500 S5 Diesel Generator

The ARK-P 1500 S5 diesel generator, produced by Arken Generator, delivers 1360 kVA prime and 1500 kVA standby power, ensuring outstanding efficiency and reliability for demanding industrial and commercial operations. Powered by the Perkins 4012-46TWG3A 12-cylinder, turbocharged, air-to-air cooled engine, it offers excellent fuel efficiency, stable performance, and long service life under continuous heavy loads. Its STAMFORD S6L1D-H alternator with electronic AVR provides ±1% voltage regulation and <5% THD, guaranteeing clean and stable power output. Designed in compliance with ISO 8528 and ISO 3046 standards, the ARK-P 1500 S5 operates at 90.5 dBA, features a corrosion-resistant canopy, and comes with a 1-year or 1000-hour warranty, making it a durable and dependable solution for both continuous and standby power generation.

Power Prime (kVA / kW)

1360 / 1088

Power Standby (kVA / kW)

1500 / 1200

Speed (r.p.m)

1500

Standard Voltage

400/230VAC

Power Factor(Cos Phi)

0.8
BrandPerkins
Power PRP [kW]1149
Model4012-46TWG3A
N° of Cylinders / Valves12/ 48
Engine Type4
Displacement [lt]45.842
AspirationTurbocharged - Air to air cooled
Bore[mm] x Stroke[mm]160x190
Compression Ratio13:1
Air FilterHeavy Duty
Cooling MethodWater Cooled (water + %50 antifreeze)
Total Coolant Capacity (lt)201
Governor TypeElectronic
Electrical System24VDC
Battery Charger Current40A
Oil Capacity [lt]177
Exhaust Gas Flow PRP [m3/min]245
Exhaust Gas Temp. [°C]479
Air Flow PRP [m3/min]108
Cooling Air Flow PRP [m3/min]28
Starter Power (kW)16,4kW
Standard Battery Voltage [V]24VDC
Standard Battery Capacity4x150Ah
Standard Battery TypeMaintenance-Free Lead Acid
BrandStamford
ModelS6L1D-H
Voltage400 /230 VAC
Number of Phase3
Power Factor0.8
Number of Poles4
Connection TypeStar
BearingSingle

Datasheet
