Mitsubishi Diesel Generator ARK-M 2100 N5

ARK-M 2100 N5 Diesel Generator – Heavy-Duty Performance for Continuous Operations

The ARK-M 2100 N5 diesel generator by Arken Generator delivers 1900 kVA prime and 2100 kVA standby power, driven by the Mitsubishi S16R-PTA2 16-cylinder, turbocharged, air-to-air cooled engine. Designed for long-term industrial use, it ensures superior durability, reduced fuel consumption, and outstanding performance under high loads.

Its Nekra ARK 7H alternator offers 97.4 % efficiency, ±1 % voltage regulation, and < 5 % THD, providing clean, stable electricity. Certified to ISO 8528 and ISO 3046, the ARK-M 2100 N5 operates at 75 dBA and includes a 2-year / 1000-hour warranty, combining efficiency and power for mission-critical operations

Power Prime (kVA / kW)

1900 / 1520

Power Standby (kVA / kW)

2100 / 1680

Speed (r.p.m)

1500

Standard Voltage

400/230VAC

Power Factor(Cos Phi)

0.8
BrandMitsubishi
Power PRP [kW]1630
ModelS16R-PTA2
N° of Cylinders / Valves16/64
Engine Type4
Displacement [lt]65,37
AspirationTurbocharged - Air to air cooled
Bore[mm] x Stroke[mm]170x180
Compression Ratio13.5:1
Air FilterHeavy Duty
Cooling MethodWater Cooled (water + %50 antifreeze)
Total Coolant Capacity (lt)445
Governor TypeElectronic
Electrical System24VDC
Battery Charger Current30A
Oil Capacity [lt]230
Exhaust Gas Flow PRP [m3/min]343
Exhaust Gas Temp. [°C]N/A
Air Flow PRP [m3/min]130
Cooling Air Flow PRP [m3/min]2040
Starter Power (kW)2x7.5kW
Standard Battery Voltage [V]24VDC
Standard Battery Capacity4x150Ah
Standard Battery TypeMaintenance-Free Lead Acid
BrandNEKRA
ModelARK 7H
Voltage400 /230 VAC
Number of Phase3
Power Factor0,8
Number of Poles4
Connection TypeStar
BearingSingle
