Baudouin Diesel Generator ARK-B 750 N5

ARK-B 750 N5 Diesel Generator – Reliable Energy for Continuous Industrial Use

The ARK-B 750 N5 diesel generator from Arken Generator provides 680 kVA prime and 750 kVA standby power using the Baudouin 6M33G750/5 6-cylinder, turbocharged, water-cooled engine. Engineered for long-term reliability, it delivers superior performance and fuel efficiency under demanding load conditions.

Featuring a NEKRA ARK 6B alternator with 94.7% efficiency, ±1% voltage regulation, and <5% THD, it ensures smooth, clean, and consistent power output. Built to ISO 8528 and ISO 3046 standards, the ARK-B 750 N5 operates at 85 dBA and includes a 2-year or 1000-hour warranty, guaranteeing dependable energy in any environment.

Power Prime (kVA / kW)

680 / 544

Power Standby (kVA / kW)

750 / 600

Speed (r.p.m)

1500

Standard Voltage

400/230VAC

Power Factor(Cos Phi)

0.8
BrandBAUDOUIN
Power PRP [kW]610
Model6M33G750/5
N° of Cylinders / Valves6/24
Engine Type4
Displacement [lt]19.6
AspirationTurbocharged - Aftercooled
Bore[mm] x Stroke[mm]150x185
Compression Ratio15:1
Air FilterHeavy Duty
Cooling MethodWater Cooled (water + %50 antifreeze)
Total Coolant Capacity (lt)159
Governor TypeElectronic
Electrical System24VDC
Battery Charger Current55
Oil Capacity [lt]61
Exhaust Gas Flow PRP [m3/min]187
Exhaust Gas Temp. [°C]≤550
Air Flow PRP [m3/min]54.6
Cooling Air Flow PRP [m3/min]783.3
Starter Power (kW)8.5
Standard Battery Voltage [V]24VDC
Standard Battery Capacity4x105Ah
Standard Battery TypeMaintenance-Free Lead Acid
BrandNEKRA
ModelARK 6B
Voltage400 /230 VAC
Number of Phase3
Power Factor0.8
Number of Poles4
Connection TypeStar
BearingSingle
