Baudouin Diesel Generator ARK-B 75 S5

ARK-B 75 S5 Diesel Generator – High-Performance Energy for Industrial Use

The ARK-B 75 S5 diesel generator from Arken Generator provides 66 kVA prime and 72.5 kVA standby power, equipped with the Baudouin 4M10G70/5 4-cylinder, turbocharged, water-cooled engine. Engineered for efficiency, it delivers superior durability, low fuel consumption, and stable output.

Featuring a Stamford UCI224F alternator with 92.5% efficiency, ±1% voltage regulation, and <5% THD, it ensures clean and reliable power production. Built in compliance with ISO 8528 and ISO 3046 standards, the ARK-B 75 S5 operates at 71.8 dBA and includes a 2-year or 1000-hour warranty, offering long-term, dependable energy generation.

Power Prime (kVA / kW)

65,9 / 52,7

Power Standby (kVA / kW)

72,5 / 58

Speed (r.p.m)

1500

Standard Voltage

400/230VAC

Power Factor(Cos Phi)

0.8
BrandBAUDOUIN
Power PRP [kW]60
Model4M10G70/5
N° of Cylinders / Valves4/8
Engine Type4
Displacement [lt]4,087
AspirationTurbocharger
Bore[mm] x Stroke[mm]105x118
Compression Ratio17,5:1
Air FilterHeavy Duty
Cooling MethodWater Cooled (water + %50 antifreeze)
Total Coolant Capacity (lt)17.9
Governor TypeElectronic
Electrical System12VDC
Battery Charger Current80
Oil Capacity [lt]13
Exhaust Gas Flow PRP [m3/min]13.04
Exhaust Gas Temp. [°C]≤570
Air Flow PRP [m3/min]3.97
Cooling Air Flow PRP [m3/min]146
Starter Power (kW)3,8
Standard Battery Voltage [V]12VDC
Standard Battery Capacity1x75Ah
Standard Battery TypeMaintenance-Free Lead Acid
BrandStamford
ModelUCI224F
Voltage400 /230 VAC
Number of Phase3
Power Factor0.8
Number of Poles4
Connection TypeStar
BearingSingle
