ARK-B 450 S5 Diesel Generator – Reliable Power for Demanding Industrial Needs

The ARK-B 450 S5 diesel generator by Arken Generator delivers 400 kVA prime and 450 kVA standby power, equipped with the Baudouin 6M21G440/5 6-cylinder, turbocharged, water-cooled engine. It offers excellent performance, durability, and low fuel consumption, making it ideal for continuous industrial applications.

Featuring a Stamford S4L1D-F alternator with 94.6% efficiency, ±1% voltage regulation, and <5% THD, it ensures clean and stable energy output. Built to ISO 8528 and ISO 3046 standards, the ARK-B 450 S5 operates at 72.6 dBA, includes a corrosion-resistant canopy, and comes with a 2-year or 1000-hour warranty, providing reliable performance in all conditions.

Power Prime (kVA / kW)

400 / 320

Power Standby (kVA / kW)

450 / 360

Speed (r.p.m)

1500

Standard Voltage

400/230VAC

Power Factor(Cos Phi)

0.8
BrandBAUDOUIN
Power PRP [kW]368
Model6M21G440/5
N° of Cylinders / Valves6/24
Engine Type4
Displacement [lt]12.54
AspirationTurbocharged - Aftercooled
Bore[mm] x Stroke[mm]127x165
Compression Ratio16:1
Air FilterHeavy Duty
Cooling MethodWater Cooled (water + %50 antifreeze)
Total Coolant Capacity (lt)55
Governor TypeElectronic
Electrical System24VDC
Battery Charger Current70
Oil Capacity [lt]30
Exhaust Gas Flow PRP [m3/min]63
Exhaust Gas Temp. [°C]≤580
Air Flow PRP [m3/min]25
Cooling Air Flow PRP [m3/min]398
Starter Power (kW)7.5
Standard Battery Voltage [V]24VDC
Standard Battery Capacity2x105Ah
Standard Battery TypeMaintenance-Free Lead Acid
BrandStamford
ModelS4L1D-F
Voltage400 /230 VAC
Number of Phase3
Power Factor0.8
Number of Poles4
Connection TypeStar
BearingSingle
