Baudouin Diesel Generator ARK-B 350 N5

ARK-B 350 N5 Diesel Generator – High-Output Energy for Heavy-Duty Industries

The ARK-B 350 N5 diesel generator from Arken Generator offers 325 kVA prime and 350 kVA standby power, powered by the Baudouin 6M16G350/5 6-cylinder, turbocharged, water-cooled engine. It’s engineered for powerful performance, fuel efficiency, and reliability in large-scale industrial environments.

Featuring a NEKRA ARK 4E alternator with 95.2% efficiency, ±1% voltage regulation, and <5% THD, it guarantees clean and stable energy output. Built to ISO 8528 and ISO 3046 standards, the ARK-B 350 N5 operates at 75 dBA and includes a 2-year or 1000-hour warranty, ensuring long-term dependable performance.

Power Prime (kVA / kW)

325 / 260

Power Standby (kVA / kW)

350 / 280

Speed (r.p.m)

1500

Standard Voltage

400/230VAC

Power Factor(Cos Phi)

0.8
BrandBAUDOUIN
Power PRP [kW]291
Model6M16G350/5
N° of Cylinders / Valves6/24
Engine Type4
Displacement [lt]9.726
AspirationTurbocharged - Aftercooled
Bore[mm] x Stroke[mm]126x130
Compression Ratio17:1
Air FilterHeavy Duty
Cooling MethodWater Cooled (water + %50 antifreeze)
Total Coolant Capacity (lt)50
Governor TypeElectronic
Electrical System24VDC
Battery Charger Current70
Oil Capacity [lt]26
Exhaust Gas Flow PRP [m3/min]58,2
Exhaust Gas Temp. [°C]≤550
Air Flow PRP [m3/min]20.8
Cooling Air Flow PRP [m3/min]450
Starter Power (kW)8.5
Standard Battery Voltage [V]24VDC
Standard Battery Capacity2x75Ah
Standard Battery TypeMaintenance-Free Lead Acid
BrandNEKRA
ModelARK 4E
Voltage400 /230 VAC
Number of Phase3
Power Factor0.8
Number of Poles4
Connection TypeStar
BearingSingle

Datasheet
