Baudouin Diesel Generator ARK-B 1650 S5

ARK-B 1650 S5 Diesel Generator – Reliable and Heavy-Duty Industrial Power

The ARK-B 1650 S5 diesel generator from Arken Generator delivers 1500 kVA prime and 1650 kVA standby power with the Baudouin 12M33G1650/5 12-cylinder, turbocharged, aftercooled engine. Engineered for performance and efficiency, it ensures stable energy output, durability, and low operational costs.

Equipped with a Stamford S7L1D-C alternator featuring 96.4% efficiency, ±1% voltage regulation, and <5% THD, it guarantees clean and consistent power. Built to meet ISO 8528 and ISO 3046 standards, the ARK-B 1650 S5 includes a 2-year or 1000-hour warranty, providing industrial-grade reliability.

Power Prime (kVA / kW)

1500 / 1200

Power Standby (kVA / kW)

1650 / 1320

Speed (r.p.m)

1500

Standard Voltage

400/230VAC

Power Factor(Cos Phi)

0.8
BrandBAUDOUIN
Power PRP [kW]1350
Model12M33G1650/5
N° of Cylinders / Valves12/ 48
Engine Type4
Displacement [lt]39.2
AspirationTurbocharged - Aftercooled
Bore[mm] x Stroke[mm]150x185
Compression Ratio15:1
Air FilterHeavy Duty
Cooling MethodWater Cooled (water + %50 antifreeze)
Total Coolant Capacity (lt)303
Governor TypeECU (Engine Control Unit)
Electrical System24VDC
Battery Charger Current55
Oil Capacity [lt]155
Exhaust Gas Flow PRP [m3/min]334,9
Exhaust Gas Temp. [°C]≤550
Air Flow PRP [m3/min]101.1
Cooling Air Flow PRP [m3/min]2100
Starter Power (kW)2x8,5
Standard Battery Voltage [V]24VDC
Standard Battery Capacity4x150Ah
Standard Battery TypeMaintenance-Free Lead Acid
BrandStamford
ModelS7L1D-C
Voltage400 /230 VAC
Number of Phase3
Power Factor0.8
Number of Poles4
Connection TypeStar
BearingSingle
