Baudouin Diesel Generator ARK-B 1500 L5

ARK-B 1500 L5 Diesel Generator – Powerful and Efficient Energy for Industrial Needs

The ARK-B 1500 L5 diesel generator by Arken Generator delivers 1350 kVA prime and 1500 kVA standby power, ensuring exceptional performance for demanding industrial operations. It is powered by the Baudouin 12M33G1500/5, a 12-cylinder, turbocharged, water-cooled diesel engine designed for durability, fuel efficiency, and stable power output.

Featuring a LINZ PRO40M D/4 alternator with 96.8% efficiency, ±1% voltage regulation, and <3% THD, it ensures reliable and clean energy supply. Built in compliance with ISO 8528 and ISO 3046 standards, the ARK-B 1500 L5 operates at 91.8 dBA, includes a corrosion-resistant canopy, and comes with a 2-year or 1000-hour warranty, making it a trusted choice for continuous and standby power applications.

Power Prime (kVA / kW)

1350 / 1080

Power Standby (kVA / kW)

1500 / 1200

Speed (r.p.m)

1500

Standard Voltage

400/230VAC

Power Factor(Cos Phi)

0.8
BrandBAUDOUIN
Power PRP [kW]1200
Model12M33G1500/5
N° of Cylinders / Valves12/48
Engine Type4
Displacement [lt]39.2
AspirationTurbocharge and Aftercooler System
Bore[mm] x Stroke[mm]150x185
Compression Ratio15:1
Air FilterHeavy Duty
Cooling MethodWater Cooled (water + %50 antifreeze)
Total Coolant Capacity (lt)303
Governor TypeElectronic
Electrical System24VDC
Battery Charger Current55
Oil Capacity [lt]155
Exhaust Gas Flow PRP [m3/min]277
Exhaust Gas Temp. [°C]≤550
Air Flow PRP [m3/min]97.3
Cooling Air Flow PRP [m3/min]2100
Starter Power (kW)10
Standard Battery Voltage [V]24VDC
Standard Battery Capacity4x150Ah
Standard Battery TypeMaintenance-Free Lead Acid
BrandLinz
ModelPRO40M D/4
Voltage400 /230 VAC
Number of Phase3
Power Factor0.8
Number of Poles4
Connection TypeStar
BearingSingle
