Baudouin Diesel Generator ARK-B 1125 S5

ARK-B 1125 S5 Diesel Generator – Industrial Power, Superior Performance

The ARK-B 1125 S5 diesel generator, produced by Arken Generator, delivers 1020 kVA prime and 1125 kVA standby power, offering exceptional reliability and performance for industrial and commercial operations. Powered by the Baudouin 12M26G1100/5 12-cylinder turbocharged engine and equipped with a STAMFORD S6L1D-E4 alternator, it ensures 96.2% efficiency, ±1% voltage regulation, and <3% THD for stable, clean power output. Built to ISO 8528 and ISO 3046 standards, it operates quietly at 89.1 dBA, features a corrosion-resistant canopy, and comes with a 2-year or 1000-hour warranty, making it an ideal choice for dependable, long-term energy generation.

Power Prime (kVA / kW)

1020 / 816

Power Standby (kVA / kW)

1125 / 900

Speed (r.p.m)

1500

Standard Voltage

400/230VAC

Power Factor(Cos Phi)

0.8
BrandBAUDOUIN
Power PRP [kW]889
Model12M26G1100/5
N° of Cylinders / Valves12/48
Engine Type4
Displacement [lt]31.8
AspirationTurbocharged - Aftercooled
Bore[mm] x Stroke[mm]150x150
Compression Ratio15,7:1
Air FilterHeavy Duty
Cooling MethodWater Cooled (water + %50 antifreeze)
Total Coolant Capacity (lt)191
Governor TypeElectronic
Electrical System24VDC
Battery Charger Current55
Oil Capacity [lt]109
Exhaust Gas Flow PRP [m3/min]182,2
Exhaust Gas Temp. [°C]≤550
Air Flow PRP [m3/min]71.3
Cooling Air Flow PRP [m3/min]1450
Starter Power (kW)10
Standard Battery Voltage [V]24VDC
Standard Battery Capacity4x105Ah
Standard Battery TypeMaintenance-Free Lead Acid
BrandSTAMFORD
ModelS6L1D-E4
Voltage400 /230 VAC
Number of Phase3
Power Factor0.8
Number of Poles4
Connection TypeStar
BearingSingle

Datasheet
