Baudouin Diesel Generator ARK-B 1035 S5

ARK-B 1035 S5 Diesel Generator – Maximum Efficiency for Continuous Power Supply

The ARK-B 1035 S5 diesel generator by Arken Generator delivers 940 kVA prime and 1010 kVA standby power, powered by the Baudouin 8M33G1000/5 8-cylinder, turbocharged, aftercooled engine. Designed for large-scale industrial applications, it provides high output, superior fuel efficiency, and extended durability.

Equipped with a Stamford S6L1D-D alternator offering 96.1% efficiency, ±1% voltage regulation, and <5% THD, it ensures clean, reliable power. Built according to ISO 8528 and ISO 3046 standards, the ARK-B 1035 S5 operates efficiently and comes with a 2-year or 1000-hour warranty, ensuring continuous, stable performance for critical operations.

Power Prime (kVA / kW)

940 / 752

Power Standby (kVA / kW)

1010 / 808

Speed (r.p.m)

1500

Standard Voltage

400/230VAC

Power Factor(Cos Phi)

0.8
BrandBAUDOUIN
Power PRP [kW]815
Model8M33G1000/5
N° of Cylinders / Valves8/32
Engine Type4
Displacement [lt]26.14
AspirationTurbocharged - Aftercooled
Bore[mm] x Stroke[mm]150x185
Compression Ratio15:1
Air FilterHeavy Duty
Cooling MethodWater Cooled (water + %50 antifreeze)
Total Coolant Capacity (lt)152
Governor TypeElectronic
Electrical System24VDC
Battery Charger Current55
Oil Capacity [lt]105
Exhaust Gas Flow PRP [m3/min]149,6
Exhaust Gas Temp. [°C]≤550
Air Flow PRP [m3/min]47.2
Cooling Air Flow PRP [m3/min]870
Starter Power (kW)8.5
Standard Battery Voltage [V]24VDC
Standard Battery Capacity4x105Ah
Standard Battery TypeMaintenance-Free Lead Acid
BrandStamford
ModelS6L1D-D
Voltage400 /230 VAC
Number of Phase3
Power Factor0.8
Number of Poles4
Connection TypeStar
BearingSingle

Datasheet
