Дизельный генератор Cummins ARK-C 170 S5
Номинальная мощность
155 / 124
Максимальная мощность
170 / 136
Скорость
1500
Напряжение
400/230VAC
Коэффициент мощности
0.8
| Brand | Cummins |
| Power PRP [kW] | 145 |
| Model | 6BTAA5.9-G7 |
| N° of Cylinders / Valves | 6 |
| Engine Type | 4 |
| Displacement [lt] | 5,9 |
| Aspiration | Turbocharged - Air to air cooled |
| Bore[mm] x Stroke[mm] | 102x120 |
| Compression Ratio | 16.5:1 |
| Air Filter | Heavy Duty |
| Cooling Method | Water Cooled (water + %50 antifreeze) |
| Total Coolant Capacity (lt) | 22,1 |
| Governor Type | Electronic |
| Electrical System | 12VDC |
| Battery Charger Current | 55 |
| Oil Capacity [lt] | 16,4 |
| Exhaust Gas Flow PRP [m3/min] | 16,4 |
| Exhaust Gas Temp. [°C] | ≤517 |
| Air Flow PRP [m3/min] | 3,77 |
| Cooling Air Flow PRP [m3/min] | 3,77 |
| Starter Power (kW) | TBA |
| Standard Battery Voltage [V] | 12VDC |
| Standard Battery Capacity | 1x105Ah |
| Standard Battery Type | Bakımsız Kurşun Asit |
| Brand | Stamford |
| Model | UCI274E |
| Voltage | 400 /230 VAC |
| Number of Phase | 3 |
| Power Factor | 0.8 |
| Number of Poles | 4 |
| Connection Type | Star |
| Bearing | Single |
