Дизельный генератор Sdec ARK-S 330 L5
Номинальная мощность
300 / 240
Максимальная мощность
330 / 264
Скорость
1500
Напряжение
400/230VAC
Коэффициент мощности
0,8
| Brand | SDEC |
| Power PRP [kW] | 255 |
| Model | SC10E380D2 |
| N° of Cylinders / Valves | 6/24 |
| Engine Type | 4 Stroke |
| Displacement [lt] | 11,8 |
| Aspiration | Turbocharged - Intercooled |
| Bore[mm] x Stroke[mm] | 128x135 |
| Compression Ratio | 17:1 |
| Air Filter | Replaceable Element |
| Cooling Method | Water Cooled (water + %50 antifreeze) |
| Total Coolant Capacity (lt) | 73,2 |
| Governor Type | Electronic |
| Electrical System | 24VDC |
| Battery Charger Current | 70A |
| Oil Capacity [lt] | 41 |
| Exhaust Gas Flow PRP [m3/min] | 43,8 |
| Exhaust Gas Temp. [°C] | 600 |
| Air Flow PRP [m3/min] | 17,3 |
| Cooling Air Flow PRP [m3/min] | TBA |
| Starter Power (kW) | 5,5kW |
| Standard Battery Voltage [V] | 24VDCc |
| Standard Battery Capacity | 2x105Ah |
| Standard Battery Type | Maintenance-Free Lead Acid |
| Brand | LINZ |
| Model | PRO28ME/4 |
| Voltage | 400 /230 VAC |
| Number of Phase | 3 |
| Power Factor | 0,8 |
| Number of Poles | 4 |
| Connection Type | Star |
| Bearing | Single |
