Дизельный генератор ARK-S 200 N5 с двигателем SDEC SC7H230D2 обеспечивает 180 кВА (prime) и 194 кВА (standby).
Альтернатор NEKRA ARK 274G с ±1% регулировкой напряжения и THD <5% гарантирует стабильное и чистое электроснабжение.
Соответствует стандартам ISO 8528 / ISO 3046, гарантия 2 года / 1000 часов — оптимальное решение для промышленных и коммерческих объектов.
| Brand | Sdec |
| Power PRP [kW] | 154 |
| Model | SC7H230D2 |
| N° of Cylinders / Valves | 6/24 |
| Engine Type | 4 Stroke |
| Displacement [lt] | 6,44 |
| Aspiration | Turbocharger |
| Bore[mm] x Stroke[mm] | 105X124 |
| Compression Ratio | 16:1 |
| Air Filter | Replaceable Element |
| Cooling Method | Water Cooled (water + %50 antifreeze) |
| Total Coolant Capacity (lt) | 28,6 |
| Governor Type | Electronic |
| Electrical System | 24VDC |
| Battery Charger Current | 55A |
| Oil Capacity [lt] | 17,5 |
| Exhaust Gas Flow PRP [m3/min] | 27,2 |
| Exhaust Gas Temp. [°C] | 600 |
| Air Flow PRP [m3/min] | 12,2 |
| Cooling Air Flow PRP [m3/min] | 271,8 |
| Starter Power (kW) | 6kW |
| Standard Battery Voltage [V] | 24VDC |
| Standard Battery Capacity | 2x75Ah |
| Standard Battery Type | Maintenance-Free Lead Acid |
| Brand | Nekra |
| Model | ARK 274G |
| Voltage | 400 /230 VAC |
| Number of Phase | 3 |
| Power Factor | 0,8 |
| Number of Poles | 4 |
| Connection Type | Star |
| Bearing | Single |
